Description
Features
• 30,000 lbs capacity
• Air-released safety lock for convenient operation and reliability
• Mechanical self-lock and cable-breaking protection
• 3/4″ aircraft quality cable
• Skid proof diamond platform
• Hydraulic cylinders are designed and made to high quality standards
• Strict quality control of cylinders with flow restrictor for a stable and smooth operational speed
• Optional Rolling Jacks:
– RJ-20A 20,000lbs pneumatic pump
| Model | PRO-30 |
| Lifting Time | 130s |
| A: Overall Length (Inc. Ramps) | 307 1/8″ (7800mm) |
| B: Overall Length (No. Ramps) | 256 1/2″ (6514mm) |
| C: Overall Width | 149 3/8″ (3794mm) |
| D: Width Between Columns | 131 3/4″ (3348mm) |
| E: Max. Lifting Height | 74 3/4″ (1900mm) |
| F: Overall Height | 91 7/8″ (2332mm) |
| G: Minimum Height | 10 1/2″ (265mm) |
| H: Max. Underneath Height | 65 7/8″ (1674mm) |
| I: Drive-Thru Clearance | 117 3/4″ (2992mm) |
| J: Width Between Runways | 54 3/4″ (1390mm) |
| K: Outside Edge of Runways | 102 3/4″ (2610mm) |
| Gross Weight | 5,362 lbs (2,432kg) |
| Motor | 2.0HP, 220V/60Hz Single Phase |
Detailed Images
- Air control safety device.
- Optional airline kit. Easy to install with all models of rolling jacks with pneumatic pump accessories. Kits No.: 40106
- Optional length extension kit adds an extra 29″ (737mm) length on the platform. Kit No. 43001 (PRO-30)
- Optional LED light kits is fitted for every model of AMGO 4-post lifts. LED Kits No.:40103
- Optional Rolling Jacks: RJ-20A 20,000lbs
