Name: PRO-12
Brand: Danbury Automotive Lifts
Price: 4785.0 USD
Availability: InStock

Features

• 12,000 lbs capacity

• Air-released safety lock for convenient operation and reliability

• Mechanical self-lock and cable-breaking protection

• 1/2″ aircraft quality cable

• Skid proof diamond platform

• Hydraulic cylinders are designed and made to high quality standards

• Adjustable lifting platform: Off-side platform can be adjusts the mounting position left or right as required. The standard distance between two platforms is 43 1/4”(1100mm) and maximum distance is 51 1/8”(1300mm).

• Strict quality control of cylinders with flow restrictor for a stable and smooth operational speed

Optional Rolling Jacks:

-J6H 6,000lbs manual control

-J6A 6,000lbs pneumatic pump

More choices:

-Optional led lights: No. 40103

-Optional extension kit: No. 41203

-Optional air line kit: No. 40102

• Five-year Warranty on Steel Components, Three-year Warranty on Hydraulic Parts and Two Years on

Electrical Components

Model	PRO-12
Style	Non-Alignment
Lifting Capacity	12,000 lbs (5,500 kg)
Lifting Time	63S
A: Overall Length (Inc.Ramps)	236 5/8″ (6012mm)
B: Overall Length (No.Ramps)	200 3/4″ (5100mm)
C: Overall Width	126 1/4″ (3208mm)
D: Width Between Columns	112 1/4″ (2852mm)
E: Max. Lifting Height	73 1/2″ (1865mm)
F: Overall Height	86″ (2185mm)
G: Minimum Height	6 5/8″ (170mm)
H: Max. Underneath Height	67 7/8″ (1724mm)
I: Drive-Thru Clearance	98 3/8″ (2498mm)
J: Width Between Runways	43 1/4″ (1100mm), Max. 51 1/8″ (1300mm)
K: Outside Edge of Runways	83 1/4″ (2116mm), Max. 91 1/8″ (2316mm)
Gross Weight	2,319lbs (1,052kg)
Motor	2.0HP, 220V/60Hz Single Phase
